Connector
An in-house connector designed for fire prevention and suppression, featuring overheat detection and a built-in extinguishing agent. It also features Korea’s first LED light designed for convenient nighttime charging.
*Product images may differ slightly from the actual product.
WEV-A07PW
- Full charge
- About 10 hours
- Charging speed
- 7kW
- Installation site
- Apartments and buildings, public institutions, shopping centers, parking lots, rest areas
*Time to a full charge varies with battery capacity, temperature and other conditions.
Charger color
Connector color
Cable color
Specifications
- Capacity
- 7kW
- Dimensions
- 310(W)x608(H)x166(D)mm
- Input
- 220Vac, 32A
- Output
- 220Vac, 32A
- Charging interface
- SAE J1772 Type1
- Display
- 7-inch touch display
- Safety features
- Input/output overvoltage and overcurrent detection, abnormal temperature, output leakage detection
- IP
- IP44
- Certifications
- OCPP 1.6, KC certification, type approval
- User authentication
- RFID card, credit card, NFC, QR payment
- Options
- Fire-prevention charger (with PLC modem)
Features of the 7kW slow charger
A compact design that space does not constrain and that is easy to install wherever you want it.
1. 7-inch touch display
An optimal UI with a screen for each situation (overheating and bad-connection warnings)
2. Exterior body
A patented design with custom colors that suits a range of settings
3. Emergency stop button
Cuts power at once in an emergency
4. Connector holder
An integrated holder keeps the cable tidy
5. Card tagging
Private card tagging limits charging to the people you choose
Charger status LED
5 colors let you read the charger’s state at a glance.
Ready to charge
The LED stays blue while the charger is on standby and during user authentication via membership card or QR code, as the charger exchanges data with the server and vehicle before charging begins.
Charging
The LED lights up green while the vehicle is charging.
Charge complete
The LED lights up blue when charging is complete.
Fault
If charging stops unexpectedly due to an issue such as abnormal temperature, overcurrent, or overvoltage, the LED blinks red.
Communication Failure
If communication fails, the LED blinks yellow, and the charger reboots after one minute.
Cable
We use air-cooled cables produced in-house by E.L. Electric. Fully integrated with the charger, they provide a safe and efficient charging experience.
Fire Prevention
A built-in temperature sensor automatically controls charging speed to provide a safe and efficient charging experience.
Introducing the fire-prevention connector
Stand-mounted
A compact charger with a slim yet sturdy stand can be installed wherever you need it.
Wall-mounted
Wall-mounted indoors without a stand, maximizing the benefits of its compact design.
Canopy
A canopy installed above an EV charging station protects the charger from rain. It helps prevent accidents during charging and ensures a safe and efficient charging environment.
WEV chargers work with every EV sold in Korea.
* For a Tesla, please have a compatible adapter ready.
